Bluesound Professional BSW150 – Network-Enabled Powered Subwoofer for Commercial Audio Systems
BSW150 Overview
The Bluesound Professional BSW150 is a compact, network-active subwoofer engineered specifically for commercial installations. Designed to seamlessly integrate into boardrooms, retail spaces, or small commercial environments, this subwoofer delivers deep, powerful bass in a discreet form factor. Its versatile installation options, including wall mounting with the provided bracket, allow for flexible placement to suit various room configurations.
Built on the robust BluOS platform, the BSW150 can be network-paired with other Bluesound Professional speakers or streamers to form a comprehensive audio system. It supports playback from local network storage and a wide array of streaming services tailored for commercial use, such as SoundMachine, Custom Channels, QSIC, SiriusXM Music for Business, Tunify, and various internet radio stations. Additionally, it features a line-level input for direct connection to other audio equipment.
BSW150 Features
-
-
Network Streaming Subwoofer System: Seamlessly integrates into BluOS-enabled audio networks.
-
8” Low-Frequency Driver: Delivers deep, accurate bass reproduction.
-
150W Power Amplifier: High-efficiency Class D amplifier provides robust performance.
-
Frequency Response: 22Hz – 150Hz for comprehensive low-end coverage.
-
Digital Signal Processing (DSP): Enables equalization and advanced audio processing.
-
App-Based Controls: Adjust volume, crossover (50–150Hz), and phase directly via the BluOS Controller app.
-
Flexible Zone Grouping: Create unlimited audio zones within a BluOS system.
-
Streaming Service Integration: Supports services including SoundMachine, Custom Channels, QSIC, and more.
-
High-Resolution Audio Support: Up to 192kHz/24-bit and MQA content compatibility.
-
Multiple Control Options: Manage settings via PC/Mac, iOS/Android devices, or third-party control systems.
-
Secure Operation: Features to prevent unauthorized control access.
-
Connectivity Options: Offers wired Ethernet and Wi-Fi streaming capabilities.
-
USB Input: Allows playback from locally connected drives.
-
Installation Flexibility: Includes wall-mount bracket for versatile placement.
-
Color Variants: Available in Black or White finishes to match various decors.
-
BSW150 Specifications
-
-
Amplifier Type: Class D
-
Continuous Power Output: 150W
-
Dynamic Peak Power: 200W
-
Woofer: 8” (203mm) polypropylene cone with rubber surround
-
Crossover Range: 50Hz – 150Hz, with LFE setting
-
Frequency Response: 22Hz – 150Hz (±2dB); LF Cutoff -10dB at 20Hz
-
Processor: ARM® Cortex™ A9, 1 GHz
-
Physical Controls: Volume +/-, Function Mode
-
App Controls: Volume +/-, Variable Crossover Frequency, Variable Phase
-
Power Supply: Universal voltage 100V–240V AC, 50/60Hz
-
Low Power Mode: Network Standby
-
Network Connectivity: Gigabit Ethernet RJ45, Wi-Fi 5 (802.11ac, dual-band)
-
USB Ports: Type-A (upgrade only), Type-B (mini) for service
-
Audio Input: Mono Low/Line Level Input
-
Dimensions (W x H x D): 447mm x 285mm x 122mm (17.6” x 11.25” x 4.8”)
-
Weight: 7.9 kg (17.5 lbs)
-
Operating Environment: 0°C to 40°C; Storage: -10°C to 50°C, 20% to 80% relative humidity
-
Ideal Applications
The BSW150 is perfectly suited for commercial environments requiring high-quality bass reinforcement, including:
-
-
Retail Stores
-
Restaurants and Cafés
-
Corporate Offices
-
Hospitality Venues
-
Fitness Centers
-
Educational Institutions
-
Houses of Worship
-
What’s Included
-
-
BSW150 Network Powered Subwoofer
-
Detachable Grille
-
6′ AC Power Cord
-
2 Magnetic Rubber Feet
-
Wall-Mount Bracket
-
Cardboard Template
-
Quick Setup Guide
-
Warranty Information
-
